UB521M Bilateral Upper Body Ergometer

SportsArt is an industry leader in rehabilitative equipment manufacturing and the UB521M Upper Body Ergometer is a therapist’s favorite modality for seated, standing or users needing wheelchair access.

Console

  • Bi-directional resistance for varied exercise and therapy sessions.
  • Optional wheelchair ramp and seat
  • Hand crank position rotates 180° for opposing or in-unison arm motion.
  • Roll away seat carriage for wheelchair patients and optional wheelchair platform.
  • Adjustable ROM radius with 4 settings at 6.5, 7.5 8.5 and 9.5 inches (16.5, 19, 21.5, 24 cm).
  • Belt drive offers quiet, smooth operation with seamless transition between forward and reverse motion.
  • Tilting console and pivoting display offer customized fit for most users in seated or standing position.
  • Optional swivel seat
  • Optional wheelchair ramp
  • Optional wheelchair tie down
  • Optional grip assist gloves

Additional information

Unit Weight

Adjustable Seat: 59.4 lbs / 27 kg, Fixed Seat: 55 lbs / 25 kg, Swivel Seat: 70.4 lbs / 32 kg, Unit: 193.6 lbs / 88 kg, Wheelchair Ramp: 68.2 lbs / 31 kg

Dimensions

69.3 x 31.5 x 75 in / 176 x 80 x 190.5 cm

Resistance

20 by 0.1 increments

Power Requirement

15A, 120V AC, grounded

Max User Weight

500 lbs / 227.3 kg

Read Outs

Workout Level, Calories, Time, RPM, Distance, METS, WATTS, Speed

Workout Programs

Custom Interval, Random, Hill, Track, Iso Kinetic, Iso Strength, Custom HR, Cardio/Weight Loss, Custom HR, ActivZone™

Tech Specs

15A 120V AC, grounded

Downloads

Sell Sheet
